Features:
1.Inverter compressor.
2.Frequency conversion electronic control.
3.DC brushless motor.
4.WiFi remote control.
Our advantages
1.Multiple anti-freeze technology.
2.Smart defrost technology.
3.Quick adjustment technology, faster and more power saving.
4.Built-in three-way valve makes installation more convenient.
5.Built-in electric heating to prevent water freezing.
6.The heat exchange area is large and the flow distribution is uniform.
7.Subcooling and anti-icing technology at the bottom of the evaporator.
Parameters Table
Model | GT09H-A | ||
Power supply | |||
Heating（air+7℃/water35℃） | Capacity | KW | 15.00 |
Heating water capacity | KW | 3.56 | |
Rated current | A | 15.48/5.60 | |
COP | W/W | 4.21 | |
Heating（air+2℃/water35℃） | Capacity | KW | 14.24 |
Heating water capacity | KW | 3.94 | |
Rated current | A | 17.19/6.08 | |
COP | W/W | 3.61 | |
Heating（air-7℃/water35℃） | Capacity | KW | 13.05 |
Heating water capacity | KW | 4.57 | |
Rated current | A | 19.92/7.02 | |
COP | W/W | 2.85 | |
Cooling(air35℃/water7℃) | Capacity | KW | 12.00 |
Input | KW | 4.31 | |
Rated current | A | 18.87/6.62 | |
EER | W/W | 2.78 | |
Hot water（air7℃/water55℃） | Capacity | KW | 12.00 |
Hot water capacity | KW | 4.27 | |
Rated current | A | 18.59/6.48 | |
COP | W/W | 2.81 | |
Outdoor air flow | m3/h | 5600 | |
(water)flow rate | m3/h | 2.6 | |
Type of sheet metal | mould or digital controlled | ||
Design pressure | MPa | 4.2 | |
Refrigerant | R32 | ||
Heating water range | ℃ | 20 - 55℃ | |
Cooling water range | ℃ | 7 - 31℃ | |
Ambient temp | ℃ | -25 ℃ - 43℃ | |
Noise level(1 M) | dB(A) | ≦55.0 | |
